Reference: Cintra 6020
GBC Cintra 6020
The Cintra 6020 is a true double-beam spectrometer covering 190-1,200 nm, with very low stray light and noise, suited to routine laboratory work and applications reaching into the NIR.
Key specifications
- Photometric system
- Double-beam, direct ratio recording
- Wavelength range
- 190-1,200 nm
- Spectral bandpass
- 0.5 to 3.0 in 0.1 nm steps (fixed 1.5 nm slit also available)
- Detector
- Silicon photodiode
- Configured to your application by our specialists
- Installed and commissioned on site
- Training and after-sales support across Jordan, the GCC and MENA
GBC Cintra 6020
Request a quoteOverview
Product overview
The Cintra 6020 is available with a fixed 1.5 nm slit or a variable slit from 0.5 to 3.0 nm in 0.1 nm steps. GBC says it challenges many higher-priced UV-Vis and UV-Vis-NIR instruments on wavelength range and stray light.
A full range of accessories is available, including sample changers, autosamplers, Peltier or water thermostatted temperature control, and reflectance spheres capable of measurement up to 1,150 nm.
Specifications
Technical specifications
13 parameters
Optics
- Photometric system
- Double-beam, direct ratio recording
- Wavelength range
- 190-1,200 nm
- Spectral bandpass
- 0.5 to 3.0 in 0.1 nm steps (fixed 1.5 nm slit also available)
- Detector
- Silicon photodiode
- Scanning speed
- 5 to 10,000 nm/min
Performance
- Stray light @220 nm (10 g/L NaI)
- < 0.0001 %T
- Stray light @340 nm (50 g/L NaNO2)
- < 0.0009 %T
- Wavelength accuracy
- ±0.01 nm
- Photometric linearity
- < 0.6% @ 3 Abs
- Photometric drift
- < 0.00012 A/hr
- Baseline flatness
- < 0.0013 A
Physical
- Dimensions (W x D x H)
- 695 x 640 x 350 mm
- Weight
- 42 kg unpacked; 86 kg packed
Features
Key features
- 01
Extended range to 1,200 nm
Reaches into the NIR region.
- 02
Variable or fixed slit
0.5-3.0 nm variable, or fixed 1.5 nm.
- 03
Broad accessory range
Sample changers, autosamplers, Peltier or water thermostatting, reflectance spheres to 1,150 nm.
