Reference: OB-S / OB-SC
OB-S and OB-SC Constant Temperature Oil Bath
Stainless steel oil bath heating from room temperature to 300°C with 2000 W far-infrared heating, available with or without circulation.
Key specifications
- Heating Power
- 2000 W
- Heating Type
- Heating tube
- Temperature Range
- RT–300°C
- Temperature Sensitivity
- OB-S: ≤2°C; OB-SC: ≤1℃
- Configured to your application by our specialists
- Installed and commissioned on site
- Training and after-sales support across Jordan, the GCC and MENA
OB-S and OB-SC Constant Temperature Oil Bath
Request a quoteOverview
Product overview
The OB-S and OB-SC are constant temperature oil baths for heating samples up to 300°C. They use high-stability operational amplifiers, a dual-slope high-precision A/D converter and far-infrared heating technology, with a stainless steel chamber and bath tank.
Both models have 2000 W heating power and a timer from 0 to 999 minutes. The OB-S has a 280 × 280 × 270 mm working chamber and temperature fluctuation of 2°C or less. The OB-SC offers tighter control of 1°C or less, a 300 × 300 × 280 mm working chamber, a 37.8 L internal volume, a circulation flow of 6 L/min and a drain valve.
The baths run on 220 V, 50/60 Hz, with 110 V available as an option.
Specifications
Technical specifications
12 parameters
Specifications
- Heating Power
- 2000 W
- Heating Type
- Heating tube
- Temperature Range
- RT–300°C
- Temperature Sensitivity
- OB-S: ≤2°C; OB-SC: ≤1℃
- Temperature Fluctuation
- OB-S: ≤2°C; OB-SC: ≤1℃
- Flow Capacity
- OB-S: /; OB-SC: 6L/min
- Timing Range
- 0-999 min
- Drain Valve
- OB-S: No; OB-SC: Yes
- Dimensions of Working Chamber
- OB-S: 280*280*270 mm; OB-SC: 300*300*280 mm
- Internal Dimensions
- OB-S: 280*280*300 mm; OB-SC: 450*300*280 mm, 37.8L
- External Dimensions
- OB-S: 440*350*340mm; OB-SC: 610*370*500mm
- Electricity
- 220 V, 50/60 Hz; Optional 110 V, 50/60 Hz
Features
Key features
- 01
High temperature range
Heats from room temperature up to 300°C for oil bath applications.
- 02
Far-infrared heating
2000 W heating tube with far-infrared technology for efficient heating.
- 03
Precise measurement
High-stability operational amplifiers and a dual-slope A/D converter support accurate control.
- 04
Circulating option
The OB-SC adds 6 L/min circulation, a drain valve and fluctuation of 1°C or less.
- 05
Stainless steel construction
Stainless steel chamber and bath tank for durability and easy cleaning.
