Reference: WB-S30
WB-S30 Reciprocating Water Bath Shaker
31 L reciprocating shaking water bath with RT to 100°C control, 20-180 rpm speed and PID control for cell culture and hybridization.
Key specifications
- Type
- Reciprocating oscillation + thermostatic water bath
- Function
- Operating Temp Range / RT～100℃
- Tem. Resolution Ratio
- 0.1℃
- Tem. Motion
- ±0.1℃
- Configured to your application by our specialists
- Installed and commissioned on site
- Training and after-sales support across Jordan, the GCC and MENA
WB-S30 Reciprocating Water Bath Shaker
Request a quoteOverview
Product overview
The WB-S30 combines a thermostatic water bath with reciprocating shaking to mix samples steadily at a constant temperature. It is used for cell culture, hybridization and molecular biology assays.
The 31 L mirror stainless steel tank operates from room temperature to 100°C with ±0.2°C uniformity and 0.1°C resolution. Shaking frequency is adjustable from 20 to 180 rpm with ±1 rpm accuracy, using an amplitude of 16 mm or 24 mm. PID feedback control keeps motor speed stable, a slow start prevents liquid splashing, and the drive locks automatically if speed goes out of control.
A large backlit LCD shows measured and set values with set and remaining time, and the timer runs up to 9999 minutes. The unit resumes after a power failure and includes over-temperature alarm, water level protection and motor shaft lock protection. A tube rack and flask holder are supplied as standard.
Specifications
Technical specifications
35 parameters
SPECIFICATIONS
- Type
- Reciprocating oscillation + thermostatic water bath
- Function
- Operating Temp Range / RT～100℃
- Tem. Resolution Ratio
- 0.1℃
- Tem. Motion
- ±0.1℃
- Tem. Uniformity
- ±0.2℃
- Reciprocal Oscillation Amplitude
- 16 or 24mm (Ex-factory is 16mm)
- Reciprocating Frequeny Range
- 20～180（r/min）
- Reciprocating Frequeny Accuracy
- ±1rpm
- Structure
- Water Tank / Mirror stainless steel
- Outer Shell
- Cold rolling steel electrostatic spraying exterior
- Upper Cover
- Mirror stainless steel
- Insulating Layer
- Polyurethane
- Heater
- Stainless Steel Heater
- Driving Mode
- Crankshaft+ double link + four wheels
- Shelf
- Mirror stainless steel
- Power rating
- 1.5kW
- Controller
- Tem. Control Mode / LCD PID Intelligent control
- Setting Mode
- Touch button setting
- Tem. Display Mode
- LCD Display
- Timer
- 0～9999 min
- Operation Function
- Fixed value operation, timing function, auto stop, quickly stop start
- Temperature Sensor
- Pt100
- Speed Sensor
- Hoare
- Additional Function
- Deviation correction, menu keys, locked, power-off memory
- Safety device
- over temperature alarm, menu locked, water full or shortage protection, Motor shaft lock protection;
- Specification
- Water Tank Size (W*L*H)(mm) / 500*310*200
- Exterior Size (W*L*H)(mm)
- 828*360*425
- Packing Size (W*L*H)(mm)
- 930*520*620
- Spring Shock Basket Size（mm）
- 395*250
- Shock Basket Largest Single Size (ml /piece)
- 100ml*12/250*8/500*6
- Inside Volume
- 31L
- Shock Basket Bearing
- 5kg/layer
- Current Rating （50Hz）
- AC220V/6.8A
- NW/GW (kg）
- 20/30
- Accessories
- Water bath flask seat, tube rack
Features
Key features
- 01
Reciprocating shaking
Frequency adjustable from 20 to 180 rpm with ±1 rpm accuracy and 16 or 24 mm amplitude.
- 02
Stable temperature
Pt100 sensor and PID control give ±0.2°C uniformity from room temperature to 100°C.
- 03
Splash-free start
Slow start design and adjustable start speed prevent liquid from splashing out of flasks.
- 04
Large backlit LCD
Displays measured value, set value, set time and remaining time together.
- 05
Power-off memory
The unit resumes operation automatically after an unexpected power interruption.
- 06
Multiple safety protections
Over-temperature alarm, water level protection, menu lock and motor shaft lock protection.
