GD Cryogenic Freezer / Industrial Freezer (-150 to -35 °C)
1100 L cryogenic freezer for deep cold treatment and bearing shrink fitting, five models from -65 to -35 °C down to -150 to -110 °C, replacing liquid nitrogen.
Key specifications
- Temperature ranges
- -65 to -35 / -80 to -50 / -100 to -70 / -120 to -90 / -150 to -110 °C
- Temperature accuracy
- ±0.5 °C
- Temperature uniformity
- ±2 °C
- Effective volume
- 1100 L
- Configured to your application by our specialists
- Installed and commissioned on site
- Training and after-sales support across Jordan, the GCC and MENA
GD Cryogenic Freezer / Industrial Freezer (-150 to -35 °C)
Request a quoteOverview
Product overview
The GD series cryogenic freezer performs deep cryogenic treatment of metals to raise hardness, wear resistance and service life, and supports bearing cold assembly, gearbox assembly and aerospace cold testing. It uses mechanical refrigeration instead of liquid nitrogen, with ±0.5 °C accuracy and ±2 °C uniformity.
Standard models are 1100 L with a 90 x 100 x 125 cm inner tank and 150 to 200 mm insulation. Temperature bands are -65 to -35, -80 to -50, -100 to -70, -120 to -90 and -150 to -110 °C. The system uses Emerson rotary and Carlyle semi-hermetic piston compressors; other sizes and loads can be customized.
Specifications
Technical specifications
8 parameters
Performance
- Temperature ranges
- -65 to -35 / -80 to -50 / -100 to -70 / -120 to -90 / -150 to -110 °C
- Temperature accuracy
- ±0.5 °C
- Temperature uniformity
- ±2 °C
Physical
- Effective volume
- 1100 L
- Inner tank size
- 90*100*125 cm
- Load capacity
- 350 kg standard (up to 500 kg quoted)
- Insulation layer
- 150 mm / 200 mm
Electrical
- Power supply
- 400V 50HZ
Features
Key features
- 01
Five temperature bands
From -65 to -35 to -150 to -110 °C.
- 02
1100 L capacity
Standard chamber with customizable size.
- 03
No liquid nitrogen
Closed refrigeration system.
From order to operation
We stay with the instrument after it arrives
Al-Shaker specifies the configuration, documents the system, and supports it across Jordan, the GCC, and MENA.
- 01
Consult
- 02
Plan
- 03
Supply
- 04
Install
- 05
Train
- 06
Support
