Sykam S 6011 / S 6111 Preparative Injection HPLC Valve

Sykam S 6011 / S 6111 preparative injection valve for HPLC; stainless steel and biocompatible PEEK versions, up to 250 bar.

Key specifications

Stator material (S 6011): Stainless steel
Pressure range (S 6011): 250 bar (3750 PSI)
Stator material (S 6111): PEEK (biocompatible)
Pressure range (S 6111): 250 bar (3750 PSI)

Configured to your application by our specialists
Installed and commissioned on site
Training and after-sales support across Jordan, the GCC and MENA

Sykam S 6011 / S 6111 Preparative Injection HPLC Valve

Overview

Product overview

Preparative Injection valve from the Sykam S 6000 series for HPLC instruments. The S 6011 has a stainless steel stator, while the S 6111 is the identical valve with an inert PEEK stator.

A preparative injection valve for autosamplers or other motor-driven applications. It has standard 1/8" ports instead of the usual 1/16", needed for high-flow preparative work, features NFI technology and ships with a 1 ml sample loop.

A variety of rotor seal materials is available to suit different applications.

Specifications

Technical specifications

6 parameters

Valve

Stator material (S 6011): Stainless steel
Pressure range (S 6011): 250 bar (3750 PSI)
Stator material (S 6111): PEEK (biocompatible)
Pressure range (S 6111): 250 bar (3750 PSI)
Port size: 1/8"
Sample loop: 1 ml, others on request

Features

Key features

01
1/8" ports
Standard 1/8" ports for high-flow preparative applications.
02
No-Flow-Interruption (NFI) technology
Reduces pressure spikes during position switching to a minimum.
03
Rotor seal options
A variety of rotor seal materials is available.
04
Steel and PEEK versions
S 6011 (stainless steel) and S 6111 (PEEK stator).
