Reference: 4ti-0575
Clear Weld Heat Seal
Optically clear, permanent heat-seal film for polypropylene plates, suited to PCR, qPCR, imaging and long-term storage from -80 °C to 110 °C.
Key specifications
- Seal type
- Optically clear, permanent, non-peelable, difficult to pierce
- Seal integrity range
- -80 °C to 110 °C
- Resistance
- DMSO and solvent resistant
- Autoclavable
- Yes, 121 °C (not recommended for PCR after autoclaving)
- Configured to your application by our specialists
- Installed and commissioned on site
- Training and after-sales support across Jordan, the GCC and MENA
Clear Weld Heat Seal
Request a quoteOverview
Product overview
Clear Weld Heat Seal is an optically clear polymer film that forms a permanent weld to polypropylene plates. Its clarity allows imaging through the seal for qPCR and colorimetric assays, and it holds a complete seal across a range from -80 °C storage to high-temperature incubation.
The seal is suitable for PCR and qPCR even without a pressurized heated lid and works in water-bath thermal cyclers. Because it cannot be peeled and is difficult to pierce, it is also used for long-term compound storage and for sealing hazardous material before disposal; samples can be accessed by pre-piercing with a blade, needle or pierce plate. It resists DMSO and solvents and can be autoclaved.
The film comes as 125 x 78 mm sheets for manual and semi-automated sheet sealers, and in several roll sizes for the Azenta Automated Roll Heat Sealer and other automated sealers.
Specifications
Technical specifications
8 parameters
- Seal type
- Optically clear, permanent, non-peelable, difficult to pierce
- Seal integrity range
- -80 °C to 110 °C
- Resistance
- DMSO and solvent resistant
- Autoclavable
- Yes, 121 °C (not recommended for PCR after autoclaving)
- Compatible plates
- Polypropylene plates, 12 to 1536 wells, SBS footprint
- Sheet format
- 125 x 78 mm, 100 sheets (4ti-0575)
- Roll formats
- 610 m x 78 mm (approx. 5,000 seals, 4ti-0573); 122 m x 78 mm (4ti-0573/122); 500 m x 115 mm (4ti-0574)
- Sterility
- Non-sterile as standard; sterilization on request
Features
Key features
- 01
Optically clear
Suitable for qPCR and imaging through the seal.
- 02
Permanent seal
Non-peelable and difficult to pierce for secure storage and hazardous waste.
- 03
Wide temperature range
Seal integrity from -80 °C to 110 °C.
- 04
Solvent resistant
Resists DMSO and solvents for compound storage.
- 05
Sheets or rolls
Sheets for manual sealers, rolls for automated sealers.
