Reference: BCN9602 (BCN9602-E / BCN9602-E1)
BCN9602 96-Well Plate Nitrogen Evaporator
Microcomputer- and PID-controlled nitrogen evaporator that blows nitrogen evenly over 96 wells, with heating up to 150 °C and independent gas needles to avoid cross-contamination.
Key specifications
- Model
- BCN9602
- Catalog number (110 V)
- BCN9602-E
- Catalog number (220 V)
- BCN9602-E1
- Accessory
- BCN02 Gas Control Valve (1 pc/box)
- Configured to your application by our specialists
- Installed and commissioned on site
- Training and after-sales support across Jordan, the GCC and MENA
BCN9602 96-Well Plate Nitrogen Evaporator
Request a quoteOverview
Product overview
The 96-Well Plate Nitrogen Evaporator is a nitrogen concentration device that combines microcomputer processing with PID control. It blows nitrogen quickly, continuously and uniformly onto the sample surface, and the heating temperature is set according to the solvent's evaporation speed and boiling point to complete rapid oxygen-free concentration. This improves the recovery and reproducibility of the target analyte.
Independent gas needles avoid cross-contamination, the 80 mm standard needles sit on a height-adjustable holder, and every blowing channel can be used alone or in combination. A protective lifting system with a scale supports safe, accurate positioning.
Typical uses are sample preparation for clinical research and testing, drug screening, hormone analysis, liquid-phase work and mass spectrometry.
Specifications
Technical specifications
15 parameters
Parameters
- Model
- BCN9602
- Temperature range
- RT+5 to 150 °C
- Timing range
- min to 99 h 59 min
- Maximum movement
- 275 mm
- Maximum gas pressure
- 0.1 MPa
- Maximum gas flow
- 10 L/min
- Air inlet outer diameter
- φ7 mm
- Needle length
- 80 mm (suitable tube diameter < φ10 mm)
- Power
- 400 W
- Power supply
- AC 110/220 V, 50/60 Hz
- Weight
- 5.5 kg
- Dimensions (L x W x H)
- 220 x 260 x 445 mm
Ordering
- Catalog number (110 V)
- BCN9602-E
- Catalog number (220 V)
- BCN9602-E1
- Accessory
- BCN02 Gas Control Valve (1 pc/box)
Features
Key features
- 01
Anti-pollution
Independent gas needles avoid cross-contamination.
- 02
Adjustable needles
Standard needle is 80 mm and the needle-holder height is adjustable.
- 03
Flexible channels
Each blowing channel can be used individually or in combination.
- 04
Vertical alignment
Each gas needle corresponds to a well in the 96-well plate and is easy to adjust.
- 05
Accurate temperature control
Accurate, wide-range temperature control that is convenient to calibrate.
- 06
Safe lifting system
Protective lifting system, with a scale for accurate positioning.
- 07
Uniform heat transfer
Excellent and uniform heat transfer.
