Reference: HSC01 / HSC02
Copure® HPLC Columns for Veterinary Residue
Copure® HPLC columns for multi-class veterinary drug residue analysis on hybrid silica with multi-bonded chemistry, usable from pH 1 to 12; 2.1 × 100 mm in 3 μm and 1.7 μm.
Key specifications
- Silica
- Hybrid silica gel with multi-bonded technology
- pH range
- 1 to 12
- Reference method
- GB 31658.17-2021 (36 types of veterinary drug residues)
- HSC01
- 2.1 mm × 100 mm, 3 μm; 1 unit/box
- Configured to your application by our specialists
- Installed and commissioned on site
- Training and after-sales support across Jordan, the GCC and MENA
Copure® HPLC Columns for Veterinary Residue
Request a quoteOverview
Product overview
Copure® HPLC columns for veterinary residue use advanced hybrid silica gel with multi-bonded technology. They offer a broad pH range of 1-12 and more stable functional groups, and the bonded phase resists loss. This supports efficient, precise detection of multiple veterinary drug residues and continuous testing under strongly acidic and basic conditions.
The page documents the determination of 36 types of veterinary drug residues referencing GB 31658.17-2021, by UPLC-MS/MS with water and methanol-acetonitrile mobile phases containing 0.1% formic acid, listing retention times and ion pairs for sulfonamides, quinolones and other compounds.
Two catalog items are listed, both 2.1 × 100 mm: HSC01 (3 μm) and HSC02 (1.7 μm).
Specifications
Technical specifications
8 parameters
Column
- Silica
- Hybrid silica gel with multi-bonded technology
- pH range
- 1 to 12
Standards
- Reference method
- GB 31658.17-2021 (36 types of veterinary drug residues)
Ordering information
- HSC01
- 2.1 mm × 100 mm, 3 μm; 1 unit/box
- HSC02
- 2.1 mm × 100 mm, 1.7 μm; 1 unit/box
Application example
- Example method
- UPLC-MS/MS (Thermo Fisher TSQ Endura); HSC01; water (0.1% formic acid) / methanol:acetonitrile 2:8 (0.1% formic acid) gradient; 0.3 mL/min; 35 °C; 5 μL
- MS conditions
- HESI source; 3500 V; sheath gas 40 arb; auxiliary gas 2 arb; ion transfer tube 380 °C; auxiliary gas 350 °C
- Analyte classes shown
- Sulfonamides and quinolones (e.g. sulfapyridine, sulfadiazine, norfloxacin, ciprofloxacin, enrofloxacin) among 36 residues
Features
Key features
- 01
pH 1-12 operating range
Hybrid silica gel with stable functional groups allows testing under strong acid and base.
- 02
Multi-bonded phase
The bonded phase is resistant to loss, giving durability and reliability.
- 03
Multi-residue method
Documented for 36 types of veterinary drug residues with retention times and ion pairs.
- 04
Two particle sizes
3 μm (HSC01) and 1.7 μm (HSC02), both 2.1 × 100 mm.
