Gridded Membrane Filters
Sterile mixed cellulose ester gridded membrane filters (0.22, 0.45 and 0.80 µm; 47 and 50 mm) for microbial enrichment and colony counting.
Key specifications
- Individually packed, 47 mm
- GM001–GM006 (100 pks/box)
- Continuous packed, 47 mm
- GM101–GM106 (150 pks/box)
- Individually packed, 47 or 50 mm, 0.22/0.45/0.80 µm
- MF047-022/045/080-MCE-GWS and MF050-022/045/080-MCE-GWS (white membrane, black grid); the same sizes with -GBS suffix (black membrane, white grid); 100 pcs/box
- Material
- Mixed cellulose ester (MCE), naturally hydrophilic, unsupported
- Configured to your application by our specialists
- Installed and commissioned on site
- Training and after-sales support across Jordan, the GCC and MENA
Gridded Membrane Filters
Request a quoteOverview
Product overview
These sterile, unsupported, naturally hydrophilic mixed cellulose ester (MCE) membranes use different pore sizes to enrich and culture specific bacteria, and are widely used in microbial analysis and research. The printed grid lines help differentiate and count colonies without affecting growth. The ink is described as nontoxic and free of growth inhibitors, with lines spaced at 3.1 mm.
The membranes are stated to comply with ISO7704, with microbial recovery above 90% and a sterilising filtration efficiency of LRV >7 (ASTM bacterial challenge test with ATCC19146). White grid membranes are designed for recovery and retention of E. coli in water and waste-water analysis and other microbiological tests; black membranes provide contrast with residues or colony colours without counter-staining. Each is irradiation sterilised, individually wrapped in an easy-peel pack (or continuously packed in some versions), with a 3-year shelf life.
Specifications
Technical specifications
13 parameters
Product codes
- Individually packed, 47 mm
- GM001–GM006 (100 pks/box)
- Continuous packed, 47 mm
- GM101–GM106 (150 pks/box)
- Individually packed, 47 or 50 mm, 0.22/0.45/0.80 µm
- MF047-022/045/080-MCE-GWS and MF050-022/045/080-MCE-GWS (white membrane, black grid); the same sizes with -GBS suffix (black membrane, white grid); 100 pcs/box
Membrane
- Material
- Mixed cellulose ester (MCE), naturally hydrophilic, unsupported
- Diameter
- 47 and 50 mm
- Pore size
- 0.22, 0.45 and 0.80 µm
- Colour and grid options
- White membrane with black or green grid; black membrane with white grid
- Grid line spacing
- 3.1 mm
Performance
- Microbial recovery rate
- >90 %
- Sterilization filtration efficiency
- LRV >7 (ATCC19146, ASTM bacterial challenge test)
Standards
- Standard
- ISO7704
Sterility
- Sterilization
- Irradiation (gamma)
- Shelf life
- 3 years
Features
Key features
- 01
High microbial recovery
Stated microbial recovery rate above 90%, with good retention and colony growth.
- 02
Grid for counting
Grid lines at 3.1 mm spacing help differentiate and count colonies without affecting growth.
- 03
Colour options
White membrane with black or green grid, or black membrane with white grid for contrast.
- 04
Sterile and ready to use
Irradiation sterilised, individually packed in easy-peel packs, with a 3-year shelf life.
- 05
Pore sizes and diameters
0.22, 0.45 and 0.80 µm pores in 47 mm and 50 mm discs.
- 06
High flow rate
Calibrated mixed cellulose esters are designed to maximise flow rate.
