Reference: 7415

Jenway 7415 Scanning UV/Visible Spectrophotometer

Scanning UV/Vis spectrophotometer covering 198 to 1000 nm with a xenon lamp, 5 nm bandwidth, 7-inch colour touchscreen and 3.6 GB internal storage.

Key specifications

Stray Light
<0.5% at 340nm and 220nm
Source Lamp
Xenon lamp
Beam Type
Single
Bandwidth
5 nm
  • Configured to your application by our specialists
  • Installed and commissioned on site
  • Training and after-sales support across Jordan, the GCC and MENA

Overview

Product overview

The Jenway 7415 is the UV/visible model of the 74 Series scanning spectrophotometers, suited to teaching, industrial QC and routine sample analysis. A xenon lamp and silicon photodiode cover 198 to 1000 nm with a 5 nm bandwidth, ±2 nm wavelength accuracy and photometric accuracy of ±0.01 Abs at 1.000 A.

The instrument is operated from a 7-inch high-definition colour touchscreen that works with gloves, allowing users to view, zoom and pick points on scans and curves. Built-in modes cover photometrics, concentration, spectrum scanning, quantitation with up to 20 standards, kinetics and multi-wavelength measurement.

Methods and results are stored in 3.6 GB of internal memory and can be moved through two front USB-A ports, a USB-B port or Ethernet. A domed sample chamber lid takes tall multi-cell changers and test tubes, and the standard model is fitted with a 10 x 10 mm cuvette holder; path lengths from 10 to 100 mm are supported with accessories.

Specifications

Technical specifications

26 parameters

Stray Light
<0.5% at 340nm and 220nm
Source Lamp
Xenon lamp
Beam Type
Single
Bandwidth
5 nm
Min Wavelength
198 nm
Max Wavelength
1000 nm
Wavelength Accuracy
± 2nm
Wavelength Reproducibility
± 0.5nm
Pathlength
10-100 mm
Min Photometric - Transmittance
0 %T
Max Photometric - Transmittance
199.9 %T
Min Photometric - Absorbance
-0.3 A
Max Photometric - Absorbance
2.5 A
Photometric Accuracy
±1%T, ±0.01Abs at 1.000 Absorbance
Detector
Silicon photodiode
Concentration
-300 to 9999
Data Logging Capability
3.6GB
Output
USB Type A x 2; USB Type B x 1; Ethernet RJ45
Display Type
Touchscreen
Materials of Construction
White ABS Plastic
Width
28 cm
Height
15.6 cm
Depth
50 cm
Supply voltage
100 to 240 V AC
Frequency
50/60 Hz
Warranty
3 years
Features

Key features

  • 01

    198 to 1000 nm range

    UV and visible scanning with a xenon lamp.

  • 02

    7-inch colour touchscreen

    Zoom and select points on scans, even with gloves.

  • 03

    Six measurement modes

    Photometrics, concentration, spectrum, quantitation, kinetics and multi-wavelength.

  • 04

    Quantitation to 20 standards

    Build calibration curves on the instrument.

  • 05

    3.6 GB internal memory

    Store methods and results for quick recall.

  • 06

    USB and Ethernet

    Front-mounted ports for data and printing.

  • 07

    Domed sample chamber

    Fits tall cell changers and test tubes.
