Walk-in Stability Chamber
Room-sized stability chamber from Kesar (KGWS series, 2,400 to 24,000 litres) for large-batch ICH studies at 20-60 °C and 40-95 %RH.
View product
Reference: KGeWS series
Eco Smart Walk-in Stability Chamber
Room-sized, energy-saving walk-in stability chamber from Kesar for large-batch ICH studies. Works on dew point control with 20-60 °C and 40-95 %RH.
Key specifications
- Temperature range
- 20 °C to 60 °C
- Humidity range
- 40 %RH to 95 %RH
- Accuracy
- ±0.5 °C and ±2.0 % RH
- Uniformity
- ±2.0 °C and ±3.0 % RH
- Configured to your application by our specialists
- Installed and commissioned on site
- Training and after-sales support across Jordan, the GCC and MENA
Eco Smart Walk-in Stability Chamber
Request a quoteOverview
Product overview
The Eco Smart Walk-in Stability Chamber is a room-scale chamber that technicians can enter to load and inspect large batches. It holds temperature and relative humidity for long-term ICH stability programmes, with every parameter logged for regulatory review.
Its distinguishing point is the dew point control principle: the cooling coil temperature follows the dew point and psychrometric chart, which Kesar says cuts power use by about 70 % and water use by about 90 % compared with a standard walk-in unit.
The chamber is built from pre-fabricated PUF-insulated modular panels assembled on site, with a reinforced floor, a water and vapour tight stainless steel interior and a 7-inch HMI touch screen. Standard models range from 8,004 to 24,200 litres, and custom sizes from 8,000 litres upward are available.
Specifications
Technical specifications
16 parameters
Performance
- Temperature range
- 20 °C to 60 °C
- Humidity range
- 40 %RH to 95 %RH
- Accuracy
- ±0.5 °C and ±2.0 % RH
- Uniformity
- ±2.0 °C and ±3.0 % RH
- Test conditions supported
- 25 °C/60 % RH, 30 °C/65 % RH, 40 °C/75 % RH, 30 °C/75 % RH
- Power saving (as published)
- Approx. 70 %
- Water saving (as published)
- Approx. 90 %
Control
- Control system
- 7" HMI with TFT colour touch screen, PLC; dew point control
Construction
- Material of construction
- STD: SS 304 interior, G.I. powder-coated exterior. GMP: SS 304 interior and exterior.
Models
- KGeWS-8KL
- 8004 L; internal 1850 x 2080 x 2080 mm; external 1970 x 2200 x 2200 mm; tray 820 x 590 mm; 16 trays
- KGeWS-10KL
- 10005 L; internal 1850 x 2600 x 2080 mm; external 1970 x 2720 x 2200 mm; tray 715 x 590 mm; 24 trays
- KGeWS-12KL
- 12020 L; internal 1850 x 2730 x 2380 mm; external 1970 x 2850 x 2500 mm; tray 750 x 590 mm; 24 trays
- KGeWS-16KL
- 16065 L; internal 2250 x 3000 x 2380 mm; external 2370 x 3120 x 2500 mm; tray 840 x 725 mm; 24 trays
- KGeWS-18KL
- 18100 L; internal 2250 x 3380 x 2380 mm; external 2370 x 3500 x 2500 mm; tray 715 x 725 mm; 32 trays
- KGeWS-20KL
- 20028 L; internal 2250 x 3740 x 2380 mm; external 2370 x 3860 x 2500 mm; tray 810 x 725 mm; 32 trays
- KGeWS-24KL
- 24200 L; internal 2480 x 4100 x 2380 mm; external 2600 x 4220 x 2500 mm; tray 900 x 800 mm; 32 trays
Features
Key features
- 01
Dew point control
Coil temperature is regulated from the dew point and psychrometric chart, with no deviation during short door openings or power failure.
- 02
Modular PUF-insulated panels
Pre-fabricated panels assembled on site, with a reinforced floor for sample load and movement.
- 03
Occupant safety
Special door lock that opens from inside, password-protected door access, person-trapped emergency stop.
- 04
Alarms and cut-offs
Temperature and RH deviation alarms, power failure alarm, extreme temperature/RH cut-off, low water level cut-off.
- 05
7-inch HMI and PLC
Touch screen with password protection; data via Ethernet to software or USB in PDF form.
- 06
Optional extras
Standby cooling and humidity systems, 8 temperature + 8 RH scanner, GSM and security alarms, 21 CFR Part 11 software.
From order to operation
We stay with the instrument after it arrives
Al-Shaker specifies the configuration, documents the system, and supports it across Jordan, the GCC, and MENA.
- 01
Consult
- 02
Plan
- 03
Supply
- 04
Install
- 05
Train
- 06
Support
