Reference: Alpha 1-4 LSCplus
Alpha 1-4 LSCplus
Tabletop freeze dryer with Wireless Shelf Technology, a 4 kg ice condenser at -55 °C and the LSCplus controller for manual or automatic process control.
Key specifications
- Ice condenser capacity
- 4 kg
- Ice condenser temperature
- -55 °C
- Controller
- LSCplus
- Dimensions of base model (W x H x D)
- 390 x 415 x 555 mm
- Configured to your application by our specialists
- Installed and commissioned on site
- Training and after-sales support across Jordan, the GCC and MENA
Alpha 1-4 LSCplus
Request a quoteOverview
Product overview
The Alpha 1-4 LSCplus is a compact benchtop unit for effective lyophilization of samples. Its wireless shelf technology allows heated shelves to be used without cables, and the LSCplus controller supports manual and automatic control for reproducible results.
Two drying methods cover most tasks. Configurations range from one heated shelf in the single-chamber method, through five or ten heatable shelves and stoppering versions, to manifolds of up to 24 connections and the LyoCube with five 256 x 300 mm shelves.
Specifications
Technical specifications
11 parameters
Performance
- Ice condenser capacity
- 4 kg
- Ice condenser temperature
- -55 °C
Control
- Controller
- LSCplus
Dimensions
- Dimensions of base model (W x H x D)
- 390 x 415 x 555 mm
- Weight
- 48 kg
Interface
- Communication port
- Ethernet
Environment
- GWP index
- 2
Configurations
- Single-chamber option
- 1 heated shelf, 200 mm diameter, -25 °C to +60 °C
- Heated-shelf option
- 5 or 10 heatable shelves, 200 mm diameter, 25 mm spacing
- Stoppering option
- 2 shelves (up to 300 x 2R vials) or 4 shelves (up to 600 x 2R vials)
- LyoCube option
- 5 heatable shelves, 256 x 300 mm, 0.38 m² total, 55 mm spacing
Features
Key features
- 01
Wireless Shelf Technology
Heated shelves without cables for the single-chamber method.
- 02
Two drying methods
Single-chamber drying on heated shelves, or double-chamber drying with the ice condenser separate.
- 03
LSCplus control
Vacuum control, pressure rise test, defrost function, product temperature and program selector.
- 04
Drying manifolds
8, 20 or 24 connections; the 8 and 20 port versions are specifically suitable for solvent drying.
- 05
Stoppering versions
Two shelves with 12 flask connections, or four shelves for up to 600 x 2R vials.
- 06
LyoCube
Five heatable shelves, 256 x 300 mm, available also with acrylic glass chamber.
From order to operation
We stay with the instrument after it arrives
Al-Shaker specifies the configuration, documents the system, and supports it across Jordan, the GCC, and MENA.
- 01
Consult
- 02
Plan
- 03
Supply
- 04
Install
- 05
Train
- 06
Support
