Reference: Beta 2-8 LSCplus
Beta 2-8 LSCplus
Benchtop freeze dryer with Wireless Shelf Technology, an 8 kg ice condenser at -85 °C and the LSCplus controller, configurable with accessories.
Key specifications
- Ice condenser capacity
- 8 kg
- Ice condenser temperature
- -85 °C
- Controller
- LSCplus
- Dimensions of base model (W x H x D)
- 780 x 415 x 540 mm
- Configured to your application by our specialists
- Installed and commissioned on site
- Training and after-sales support across Jordan, the GCC and MENA
Beta 2-8 LSCplus
Request a quoteOverview
Product overview
The Beta 2-8 LSCplus is a compact tabletop unit for effective lyophilization with wireless shelf technology. The -85 °C condenser suits specimens with low eutectic points.
The LSCplus controller offers manual and automatic process control, and two drying methods are available. Configurations include single-chamber drying on a heated shelf, five or ten heatable shelves, stoppering versions, manifolds of 8 to 24 connections and the LyoCube.
Specifications
Technical specifications
11 parameters
Performance
- Ice condenser capacity
- 8 kg
- Ice condenser temperature
- -85 °C
Control
- Controller
- LSCplus
Dimensions
- Dimensions of base model (W x H x D)
- 780 x 415 x 540 mm
- Weight
- 78 kg
Interface
- Communication port
- Ethernet
Environment
- GWP index
- ≤ 6
Configurations
- Single-chamber option
- Heated shelf, optionally with fan, with or without stoppering device
- Heated-shelf options
- 5 or 10 heatable shelves with 12 additional flask connections; 2 shelves with stoppering device
- Manifold options
- 8, 20 or 24 connections
- LyoCube option
- 5 heatable shelves, 256 x 300 mm
Features
Key features
- 01
Wireless Shelf Technology
Heated shelves without cables for the single-chamber method.
- 02
Two drying methods
Single-chamber drying on heated shelves, or double-chamber drying with the ice condenser separate.
- 03
LSCplus control
Vacuum control, pressure rise test, defrost function, product temperature and program selector.
- 04
8 kg ice condenser
Condenser temperature of -85 °C.
- 05
Manifold options
8, 20 or 24 connections, including solvent-suitable versions.
- 06
LyoCube
Five heatable shelves, 256 x 300 mm, also with acrylic glass chamber.
