Reference: Delta 2-24 LSCplus
Delta 2-24 LSCplus
Compact mobile floor-standing freeze dryer with a 24 kg ice condenser at -85 °C and Wireless Shelf Technology for demanding laboratory applications.
Key specifications
- Ice condenser capacity
- 24 kg
- Ice condenser temperature
- -85 °C
- Controller
- LSCplus
- Dimensions of base model (W x H x D)
- 860 x 1050 x 650 mm
- Configured to your application by our specialists
- Installed and commissioned on site
- Training and after-sales support across Jordan, the GCC and MENA
Delta 2-24 LSCplus
Request a quoteOverview
Product overview
The Delta 2-24 LSCplus is a floor-mounted laboratory freeze dryer in a compact, mobile design for demanding applications. Its ice condenser holds 24 kg at -85 °C, which suits specimens with low eutectic points.
It uses wireless shelf technology and the LSCplus controller for manual and automatic process control. Configurations range from ten heatable shelves in the single-chamber method to stoppering versions with four shelves, an eight-shelf version with optional lifting device and a manifold with 24 connections.
Specifications
Technical specifications
10 parameters
Performance
- Ice condenser capacity
- 24 kg
- Ice condenser temperature
- -85 °C
Control
- Controller
- LSCplus
Dimensions
- Dimensions of base model (W x H x D)
- 860 x 1050 x 650 mm
- Weight
- 250 kg
Interface
- Communication port
- Ethernet
Environment
- GWP index
- ≤ 6
Configurations
- Single-chamber options
- 10 heatable shelves, or 4 heatable shelves with stoppering device, optionally with fan
- Double-chamber options
- 10 heatable shelves with 12 flask connections; 4 shelves with stoppering device; 8 heatable shelves
- Manifold option
- Two drying chambers with 24 connections
Features
Key features
- 01
Wireless Shelf Technology
Heated shelves without cables for the single-chamber method.
- 02
Two drying methods
Single-chamber drying on heated shelves, or double-chamber drying with the ice condenser separate.
- 03
LSCplus control
Vacuum control, pressure rise test, defrost function, product temperature and program selector.
- 04
24 kg ice condenser
Condenser temperature of -85 °C.
- 05
Mobile floor-standing design
Footprint of 860 x 1050 x 650 mm.
- 06
Eight-shelf version
Optional lifting device for the drying chamber.
