Alpha 2-4 LSCplus
Compact tabletop freeze dryer with Wireless Shelf Technology: 4 kg ice condenser at −85 °C, LSCplus control, Ethernet, GWP ≤ 6.
View product
Reference: Epsilon 2-16D LSCplus
Epsilon 2-16D LSCplus
Free-standing pilot freeze dryer for tray goods with a 16 kg ice condenser at -85 °C, suited to bulk material and low-eutectic or solvent-containing specimens.
Key specifications
- Ice condenser capacity
- 16 kg
- Ice condenser temperature
- -85 °C
- Shelf dimensions (W x D)
- 300 x 400 mm
- Number of shelves
- 1 - 12
- Configured to your application by our specialists
- Installed and commissioned on site
- Training and after-sales support across Jordan, the GCC and MENA
Epsilon 2-16D LSCplus
Request a quoteOverview
Product overview
The Epsilon 2-16D LSCplus is a general-purpose, high-performance pilot unit with stainless steel shelves that have internal heat-transfer media channels, meeting the demands of the pharmaceutical and biotechnology industries. It offers drying on up to ten shelves with a total area of 1.2 m² and a shelf spacing of 83 mm.
The unit is intended for small-scale production of bulk material, in particular pharmaceutical specimens with low eutectic or collapse temperatures and products containing solvents.
Specifications
Technical specifications
13 parameters
Performance
- Ice condenser capacity
- 16 kg
- Ice condenser temperature
- -85 °C
- Ice condenser volume
- 108 litres
Shelves
- Shelf dimensions (W x D)
- 300 x 400 mm
- Number of shelves
- 1 - 12
- Shelf area
- 1.44 - 0.12 m²
- Shelf spacing
- 83 mm
- Shelf temperature
- -60 °C to +60 °C
- Shelf temperature accuracy
- max. ±1 °C
Cooling
- Cooling system
- Independent systems, water cooled
- Ice condenser cooling system
- 5.5 kW compressors, two-stage
- Shelf cooling system
- 3.3 kW compressor
Dimensions
- Unit dimensions
- 2002 x 1562 x 836 (H x W x D) mm
Features
Key features
- 01
Tray drying
Shelves of 300 x 400 mm, 83 mm spacing.
- 02
108 litre ice condenser
16 kg capacity at -85 °C, two-stage compressors.
- 03
Cleanroom and H2O2 options
Cleanroom installation and VHP disinfection possible.
- 04
WTMplus 2.0 wireless temperature measurement
Optional wireless sensors, measuring range -60 °C to +135 °C, accuracy ±1.0 K.
- 05
Comparative pressure measurement
Two vacuum sensors with different principles indicate the end of primary drying.
- 06
Solvent-resistant version
Chemical-resistant valves, door seals and vacuum pump for solvent-containing products.
From order to operation
We stay with the instrument after it arrives
Al-Shaker specifies the configuration, documents the system, and supports it across Jordan, the GCC, and MENA.
- 01
Consult
- 02
Plan
- 03
Supply
- 04
Install
- 05
Train
- 06
Support
Keep exploring
More from Martin Christ
Alpha 1-2 LSCbasic
Everyday tabletop freeze dryer: 2.5 kg ice condenser at −55 °C, LSCbasic touch, USB + LAN, GWP 2 — 315 × 345 × 470 mm, 32 kg.
View product
Gamma 2-16 LSCplus
Compact benchtop freeze dryer for larger sample quantities: 16 kg ice condenser at −85 °C, LSCplus, Ethernet, GWP ≤ 6.
View product
Epsilon 2-10D LSCplus
Pilot freeze dryer for small-batch production: 10 kg ice condenser at −88 °C, 1–7 shelves 350 × 400 mm (0.14–0.98 m²), ±1 °C.
View product
Talk to the technical team
Tell us the application. We will specify the system.
Share the workflow, capacity, and compliance constraints. We respond with a recommended configuration, not a generic catalogue list.
