Alpha 2-4 LSCplus
Compact tabletop freeze dryer with Wireless Shelf Technology: 4 kg ice condenser at −85 °C, LSCplus control, Ethernet, GWP ≤ 6.
View product
Reference: Epsilon 2-4 LSCplus
Epsilon 2-4 LSCplus
Compact, universal tabletop pilot freeze dryer with a 4 kg cascade ice condenser at -88 °C, suited to low-eutectic pharmaceutical specimens and solvent-containing products.
Key specifications
- Ice condenser capacity
- 4 kg
- Ice condenser temperature
- -88 °C
- Shelf dimensions (W x D)
- 270 x 400 mm
- Number of shelves
- 1
- Configured to your application by our specialists
- Installed and commissioned on site
- Training and after-sales support across Jordan, the GCC and MENA
Epsilon 2-4 LSCplus
Request a quoteOverview
Product overview
The Epsilon 2-4 LSCplus is a very compact, general-purpose high-performance laboratory and pilot unit for tabletop installation, covering routine drying through process optimisation.
It dries solid or liquid, mainly aqueous products in vials, ampoules, tubes, glass containers or dishes, in particular pharmaceutical specimens with low eutectic points and products containing solvents. A two-compressor cascade gives the -88 °C condenser temperature and shelves cool to -70 °C.
Specifications
Technical specifications
14 parameters
Performance
- Ice condenser capacity
- 4 kg
- Ice condenser temperature
- -88 °C
- Ice condenser volume
- 40 litres
Shelves
- Shelf dimensions (W x D)
- 270 x 400 mm
- Number of shelves
- 1
- Shelf area
- 0.108 m²
- Shelf spacing
- 140 mm with sealing device; 172 mm without
- Shelf temperature
- -70 °C to +60 °C
- Shelf temperature accuracy
- max. ±2 °C
Cooling
- Cooling system
- Air cooled (optionally water cooled)
- Ice condenser cooling system
- 2 compressors, 0.51 kW each, in cascade configuration
- Shelf cooling system
- (see ice condenser cooling system)
Dimensions
- Unit dimensions
- 780 x 975 x 530 (H x W x D) mm
Environment
- GWP index
- ≤ 6
Features
Key features
- 01
-88 °C cascade condenser
Two compressors of 0.51 kW each, 4 kg capacity.
- 02
Shelf range -70 °C to +60 °C
Teflon-coated solid aluminium shelf, accuracy max. ±2 °C.
- 03
Integrated drying manifold
Supports round-bottom flasks and wide-neck bottles.
- 04
WTMplus 2.0 wireless temperature measurement
Optional wireless sensors, measuring range -60 °C to +135 °C, accuracy ±1.0 K.
- 05
Comparative pressure measurement
Two vacuum sensors with different principles indicate the end of primary drying.
- 06
Pharma options
Cleanroom installation, glove box connection, stoppering devices and H2O2 disinfection (depending on model).
- 07
Solvent-resistant version
Chemical-resistant valves, door seals and vacuum pump for solvent-containing products.
From order to operation
We stay with the instrument after it arrives
Al-Shaker specifies the configuration, documents the system, and supports it across Jordan, the GCC, and MENA.
- 01
Consult
- 02
Plan
- 03
Supply
- 04
Install
- 05
Train
- 06
Support
