Reference: Epsilon 2-6D LSCplus
Epsilon 2-6D LSCplus
Compact floor-standing pilot freeze dryer with a 6 kg ice condenser at -88 °C and up to six shelves for process optimisation and development.
Key specifications
- Ice condenser capacity
- 6 kg
- Ice condenser temperature
- -88 °C
- Shelf dimensions (W x D)
- 225 x 300 mm
- Number of shelves
- 1 to 6
- Configured to your application by our specialists
- Installed and commissioned on site
- Training and after-sales support across Jordan, the GCC and MENA
Epsilon 2-6D LSCplus
Request a quoteOverview
Product overview
The Epsilon 2-6D LSCplus is a general-purpose, high-performance laboratory and pilot unit for drying solid or liquid products in vials, ampoules, tubes, other glass containers or dishes.
Applications include bacteria and cultures, viruses, blood plasma, serum fractions, antibodies, vaccines, medicines such as chloramphenicol or streptomycin, vitamins, biomass and plant extracts for biochemical tests. It also suits product development and small-scale production.
Specifications
Technical specifications
13 parameters
Performance
- Ice condenser capacity
- 6 kg
- Ice condenser temperature
- -88 °C
Shelves
- Shelf dimensions (W x D)
- 225 x 300 mm
- Number of shelves
- 1 to 6
- Shelf area
- 0.0675 m² to 0.3375 m²
- Shelf spacing
- 249 mm to 31 mm
- Shelf temperature
- -50 °C to +60 °C
- Shelf temperature accuracy
- max. ±1 °C
Cooling
- Cooling system
- 2 independent systems, air cooled (optionally water cooled)
- Ice condenser cooling system
- 2 compressors, 0.6 kW each, in cascade configuration
- Shelf cooling system
- 1 compressor, 0.6 kW
Dimensions
- Unit dimensions
- 1267 x 860 x 650 (H x W x D) mm
Environment
- GWP index
- ≤ 6
Features
Key features
- 01
Up to six shelves
0.0675 m² to 0.3375 m² shelf area, spacing 249 mm to 31 mm.
- 02
Two independent cooling systems
Air cooled, optionally water cooled.
- 03
Shelf range -50 °C to +60 °C
Shelf temperature accuracy max. ±1 °C.
- 04
WTMplus 2.0 wireless temperature measurement
Optional wireless sensors, measuring range -60 °C to +135 °C, accuracy ±1.0 K.
- 05
Comparative pressure measurement
Two vacuum sensors with different principles indicate the end of primary drying.
- 06
Pharma options
Cleanroom installation, glove box connection, stoppering devices and H2O2 disinfection (depending on model).
- 07
Solvent-resistant version
Chemical-resistant valves, door seals and vacuum pump for solvent-containing products.
