Reference: Zeta-1 to Zeta-13
Zeta Pharma Production Series
Modular, steam-sterilizable freeze dryers with loading and unloading systems for cGMP vial production, in six sizes from 1 to 13 m² shelf area.
Key specifications
- Models
- Zeta-1, Zeta-2, Zeta-4, Zeta-6, Zeta-10, Zeta-13
- Max. shelf area (m²)
- 1.1 / 2.2 / 4.1 / 5.8 / 10 / 13
- Number of shelves
- 2-5 / 4-6 / 5-8 / 6-8 / 6-10 / 7-9
- Shelf dimensions (W x D) in mm
- 500 x 450 / 600 x 600 / 600 x 850 / 850 x 850 / 850 x 1,200 / 1,200 x 1,200
- Configured to your application by our specialists
- Installed and commissioned on site
- Training and after-sales support across Jordan, the GCC and MENA
Zeta Pharma Production Series
Request a quoteOverview
Product overview
The Zeta series is a range of steam-sterilizable freeze dryers with loading and unloading systems designed for cGMP pharmaceutical production. The six preconfigured models, Zeta-1 to Zeta-13, cover production sizes from 1 to 13 m² of shelf area and ice capacities of 12 to 141 kg.
Standard equipment includes the LPCplus SCADA system, a slot door for connection to loading systems, CIP and SIP and a filter integrity test. Compact models with loading system and optional PAT tools can be integrated into a filling line with containment. Options such as LyoCam, LyoCoN, WTMplus and MTMplus support process monitoring.
Specifications
Technical specifications
9 parameters
Series
- Models
- Zeta-1, Zeta-2, Zeta-4, Zeta-6, Zeta-10, Zeta-13
Shelves
- Max. shelf area (m²)
- 1.1 / 2.2 / 4.1 / 5.8 / 10 / 13
- Number of shelves
- 2-5 / 4-6 / 5-8 / 6-8 / 6-10 / 7-9
- Shelf dimensions (W x D) in mm
- 500 x 450 / 600 x 600 / 600 x 850 / 850 x 850 / 850 x 1,200 / 1,200 x 1,200
Performance
- Ice capacity (kg)
- 12 / 24 / 45 / 63 / 111 / 141
Capacity
- Batch volume (approx. litres, 10R vials, 1 cm fill)
- 7.8 / 15.2 / 29.0 / 40.8 / 72.8 / 94.0
- Max. number of 2R vials
- 4,880 / 9,546 / 18,056 / 25,624 / 45,150 / 57,663
- Max. number of 10R vials
- 2,100 / 4,116 / 7,840 / 11,040 / 19,670 / 25,398
Features
- Standard equipment
- LPCplus SCADA, slot door, CIP/SIP, filter integrity test (FIT)
Features
Key features
- 01
Six sizes
Zeta-1 (1.1 m²) to Zeta-13 (13 m²), ice capacity 12 to 141 kg.
- 02
cGMP design
Steam-sterilizable with CIP and SIP and a filter integrity test.
- 03
LPCplus SCADA
Intuitive control and visualisation by Martin Christ.
- 04
Loading and unloading
LyoShuttle, pusher systems or frame loading.
- 05
PAT options
LyoCam, LyoCoN controlled nucleation, WTMplus and MTMplus.
- 06
Scale-up support
Project management to increase production capacity.
