Reference: 6100
SCION LC6000 6100 HPLC Pump Spares and Consumables
Mixers, seals, check valves, plunger wash parts and tubing for the SCION 6100 quaternary HPLC pump, listed by part number.
Key specifications
- Dynamic Mixer (2000µL)
- LC20200019
- Semi-micro Mixer (200µL)
- LC20200020
- Conventional Static Mixer (700µL)
- LC20200021
- THF Kit
- LC20200022
- Configured to your application by our specialists
- Installed and commissioned on site
- Training and after-sales support across Jordan, the GCC and MENA
SCION LC6000 6100 HPLC Pump Spares and Consumables
Request a quoteOverview
Product overview
This page lists the spare parts and consumables for the SCION 6100 HPLC pump of the LC 6000 series. Each item is identified by a SCION part number so that replacements can be ordered directly.
Parts include dynamic (2000 uL), semi-micro (200 uL) and static (700 uL) mixers, a THF kit, hexane check valve set and cartridge, plunger wash components, packings, pump and drain valve seals, check valves in and out, a flow path filter and PEEK tubing and connectors.
The pump itself is described on the LC 6000 system page; a periodical replacement parts kit is also listed for routine maintenance.
Specifications
Technical specifications
22 parameters
6100 HPLC Pump
- Dynamic Mixer (2000µL)
- LC20200019
- Semi-micro Mixer (200µL)
- LC20200020
- Conventional Static Mixer (700µL)
- LC20200021
- THF Kit
- LC20200022
- Hexane Check Valve Set
- LC20200024
- Plunger Wash
- LC20200004; LC20210003
- Packing
- LC20210004
- Check Valve
- LC20210005
- Seal
- LC20210007
- Cleaner Seal
- LC20210008
- Drain Valve Seal
- LC20210009
- Pump Seal 4
- LC20210010
- Packing (PEEK)
- LC20210011
- Periodical Replacement Parts Kit AM
- LC20210014
- Check Valve In
- LC20210021
- Check Valve Out
- LC20210279
- Flow Path Filter, size 10
- LC20210286
- Plunger Seal
- LC20210034
- Cartridge for Hexane
- LC20210035
- PEEK Tubing Orange Stripe 1/16th 0.020ID, 3M
- LC21000003
- PEEK Column Connectors, Pack of 10
- LC21000004
- Clean Cut Tubing Cutter
- LC21000005
Features
Key features
- 01
Mixer options
Dynamic 2000 uL, semi-micro 200 uL and static 700 uL mixers.
- 02
Seals and valves
Pump seals, drain valve seal, plunger seal and check valves in and out.
- 03
Periodical replacement kit
Kit for scheduled maintenance of the pump.
