Reference: VF500-86G SX
VF500-86G SX Upright ULT Freezer (-86 °C)
Upright -86 °C ultra-low temperature freezer from the EvoSafe range with 506 L total volume and room for 384 two-inch boxes, for long-term sample storage.
Key specifications
- Total volume
- 506 L
- Usable volume (2/4 compartments)
- 472/466 L
- Storage capacity, 2" boxes (50 mm)
- 384 boxes
- External dimensions (w x d x h)
- 905/850 x 888 x 1999,5 mm
- Configured to your application by our specialists
- Installed and commissioned on site
- Training and after-sales support across Jordan, the GCC and MENA
VF500-86G SX Upright ULT Freezer (-86 °C)
Request a quoteOverview
Product overview
The VF500-86G SX is an upright ultra-low temperature freezer in Snijders Labs' EvoSafe range. It holds 506 litres in total (472/466 L usable depending on whether 2 or 4 compartments are used) and has room for 384 two-inch boxes on height-adjustable stainless steel platforms behind insulated inner doors.
It uses two inverter-driven cascade refrigeration circuits (R290 and R170) and is published at 9,4 kWh per 24 hours at a -80 °C setpoint and 48 dBA. Temperature, history and alarms are handled by a 7-inch web-based touchscreen at eye level, with USB and Ethernet connections and e-mail alarming.
Racking, water cooling, CO2 or LN2 backup, a chart recorder and IQ/OQ/PQ documentation are offered as options; the datasheet lists the full specification.
Specifications
Technical specifications
18 parameters
Capacity
- Total volume
- 506 L
- Usable volume (2/4 compartments)
- 472/466 L
- Storage capacity, 2" boxes (50 mm)
- 384 boxes
Dimensions
- External dimensions (w x d x h)
- 905/850 x 888 x 1999,5 mm
- Internal dimensions (w x d x h)
- 600 x 626,5/592 x 1345 mm
- Compartments / inner doors / platforms
- 4/2/3
Cooling
- Temperature range
- -50 to -86 °C
- Cooling system
- Two cascade-connected inverter compressors
- Refrigerants
- First stage R290 / second stage R170
- Condenser
- Air-cooled
Controller
- Display
- 7" web-based touchscreen in main door at eye level
Electrical
- Supply
- 220/240 VAC, 50 Hz, 16 A slow fuse
- Power and current rating
- 450 VA/400 W/2,1 A
- Energy consumption (setpoint -80 °C)
- 9,4 kWh/24h
- Heat exchange
- 0,26 kW/h
General
- Noise level
- 48 dBA
- Net weight
- 343 kg
- Safety standards
- CE certified: EN61010-1:2010, EN60601-1-2:2007
Features
Key features
- 01
Web-based 7-inch touchscreen
Controller at eye level in the main door with scrollable temperature history and at least 12 months of data storage.
- 02
Cascade cooling with inverter compressors
Two cascade-connected inverter compressors with R290 and R170.
- 03
Alarming and monitoring
Optical and acoustic alarms, e-mail via Ethernet, potential-free contact and a backup battery that keeps alarming active during a power failure.
- 04
Flexible interior
Height-adjustable stainless steel platforms and insulated stainless steel inner doors; 4/2/3 compartments, inner doors and platforms.
- 05
Backup and service options
Optional water cooling, CO2 or LN2 backup, chart recorder, voltage stabilizer, transformer and IQ/OQ/PQ.
From order to operation
We stay with the instrument after it arrives
Al-Shaker specifies the configuration, documents the system, and supports it across Jordan, the GCC, and MENA.
