Reference: BWB Li
BWB Lithium Flame Photometer
Dedicated lithium flame photometer with four independent lithium detection channels, each calibratable with up to 10 points, for BWB's most accurate Li measurement.
Key specifications
- Element measured
- Lithium, on 4 independent Li channels with up to 10 calibration points each
- Single-point calibration
- Li 0.05-50 ppm
- Multi-point calibration
- Li 0.05-1000 ppm
- Limit of detection
- Li 0.02 ppm
- Configured to your application by our specialists
- Installed and commissioned on site
- Training and after-sales support across Jordan, the GCC and MENA
BWB Lithium Flame Photometer
Request a quoteOverview
Product overview
The BWB Li is a single-purpose flame photometer for lithium. BWB adapted and optimised its proprietary optical array so that the instrument uses multiple lithium detection channels, and describes it as its most accurate lithium flame photometer to date. The configuration was developed with customer input, including assistance from the University of Mississippi.
Four independent lithium channels can each hold up to 10 calibration points, so different concentration ranges can be covered without recalibrating. Detection reaches 0.02 ppm Li with quantification from 0.05 ppm, and cross-interference between Na, K and Li is specified at below 0.5 %.
The instrument includes a built-in air compressor, solutions and labware, and connects to BWB's FP-PC software. Outputs include USB, a 0-2.5 V analogue signal with optional 4-20 mA, and an optional integrated printer.
Specifications
Technical specifications
17 parameters
Performance
- Element measured
- Lithium, on 4 independent Li channels with up to 10 calibration points each
- Limit of detection
- Li 0.02 ppm
- Limit of quantification
- Li 0.05 ppm
- Precision
- <1 % coefficient of variation for 20 consecutive samples over 10 minutes at ≤100 ppm (after stabilisation)
- Chemical interference
- Na/K/Li <0.5 % to each other at equal concentrations below 100 ppm
- Time to stability
- Less than 15 s after the sample enters the flame
- Minimum warm-up time
- 25 minutes at 21 °C ambient
Range
- Single-point calibration
- Li 0.05-50 ppm
- Multi-point calibration
- Li 0.05-1000 ppm
Sample handling
- Sample uptake
- 2-3.5 mL/min
Interface
- Display
- Four-line back-lit alphanumeric LCD
- Outputs
- USB; 0-2.5 V analogue output (optional 4-20 mA instead); optional integrated printer; CSV/PDF reports via FP-PC software
Physical
- Operating footprint
- 50 x 45 x 45 cm (H x W x D); 1 m clear space required above the chimney
- Instrument weight
- 14 kg (30.8 lb)
Utilities
- Power supply
- 100-250 V AC, 50/60 Hz, auto-selecting
- Fuel gas
- Propane, butane or natural gas (natural gas with modifications; propane or butane recommended); regulated to 19 Bar as stated by BWB; flow 0.4 L/min
Supplied
- Calibration standards
- 4 x 150 mL 10,000 ppm lithium standard
Features
Key features
- 01
Four lithium channels
Independent channels, each with up to 10 calibration points, cover several concentration ranges.
- 02
Low interference
Na/K/Li cross-interference below 0.5 % at equal concentrations under 100 ppm.
- 03
Built-in air compressor
Supplied with solutions and labware; just add gas.
- 04
FP-PC connectivity
Data sharing and CSV/PDF reports via BWB's PC software.
- 05
IQ/OQ/PQ available
Web-based certification for regulated users.
