Reference: BWB SOIL
BWB Soil Flame Photometer
Portable flame photometer for fertiliser and soil analysis, measuring sodium, potassium and calcium together with enhanced Ca detection and a thermal printer fitted as standard.
Key specifications
- Elements measured
- Na, K and Ca simultaneously; lithium optional as internal reference
- Single-point calibration
- Na 0.1-60 ppm; K 0.05-100 ppm; Ca 1.0-100 ppm
- Multi-point calibration
- Na 0.1-1000 ppm; K 0.05-1000 ppm; Ca 1.0-1000 ppm
- Limit of detection
- Na 0.03 ppm; K 0.02 ppm; Ca 0.3 ppm
- Configured to your application by our specialists
- Installed and commissioned on site
- Training and after-sales support across Jordan, the GCC and MENA
BWB Soil Flame Photometer
Request a quoteOverview
Product overview
The BWB SOIL flame photometer was developed for the analysis of fertilisers and soil substrates, building on research by Professor Akiharu Sasaki on flame photometry in agriculture. It is based on the XP platform and optimised for agricultural laboratories.
It measures sodium, potassium and calcium simultaneously, with enhanced calcium detection, and lithium can be used as an internal reference standard. Calcium results are corrected for interference from high sodium.
Because it only needs a gas supply and is easy to move, the SOIL can be installed in the back of a van for on-site field analysis. A thermal printer is fitted as standard to keep sample traceability, and the unit can work with BWB's collection cup or the AFHS automated sample handling system.
Specifications
Technical specifications
17 parameters
Performance
- Elements measured
- Na, K and Ca simultaneously; lithium optional as internal reference
- Limit of detection
- Na 0.03 ppm; K 0.02 ppm; Ca 0.3 ppm
- Limit of quantification
- Na 0.1 ppm; K 0.05 ppm; Ca 1 ppm
- Precision
- <1 % coefficient of variation for 20 consecutive samples over 10 minutes at ≤100 ppm (after stabilisation)
- Specificity
- Na/K/Li <1 % to each other at equal concentrations below 100 ppm
- Time to stability
- Less than 15 s after the sample enters the flame
- Minimum warm-up time
- 25 minutes at 21 °C ambient
Range
- Single-point calibration
- Na 0.1-60 ppm; K 0.05-100 ppm; Ca 1.0-100 ppm
- Multi-point calibration
- Na 0.1-1000 ppm; K 0.05-1000 ppm; Ca 1.0-1000 ppm
Sample handling
- Sample uptake
- 2-3.5 mL/min
- Sampling options
- BWB collection cup or AFHS automated sample handling
Interface
- Display
- Four-line back-lit alphanumeric LCD
- Outputs
- USB; 0-2.5 V analogue (optional 4-20 mA instead); integrated thermal printer; CSV/PDF via FP-PC
Physical
- Operating footprint
- 50 x 45 x 45 cm (H x W x D); 1 m clear space required above the chimney
- Instrument weight
- 14 kg (30.8 lb)
Utilities
- Power supply
- 100-250 V AC, 50/60 Hz, auto-selecting
- Fuel gas
- Propane, butane or natural gas (natural gas with modifications; propane or butane recommended); regulated to 19 Bar as stated by BWB; flow 0.4 L/min
Features
Key features
- 01
Three nutrients at once
Na, K and Ca are detected and displayed simultaneously.
- 02
Field-portable
Just-add-gas design can be set up in a van for on-site analysis.
- 03
Thermal printer as standard
Printed records maintain sample traceability.
- 04
Internal reference standard
Lithium can be used as an internal standard.
- 05
Automation ready
Works with the BWB collection cup or AFHS autosampler.
From order to operation
We stay with the instrument after it arrives
Al-Shaker specifies the configuration, documents the system, and supports it across Jordan, the GCC, and MENA.
- 01
Consult
- 02
Plan
- 03
Supply
- 04
Install
- 05
Train
- 06
Support
