Reference: ASPIROS / ASPIROS/L
ASPIROS micro dosing unit
Micro dosing system that feeds a few micrograms up to 1,000 µg of valuable or toxic dry powder from encapsulated sample vials into RODOS dispersion.
Key specifications
- Sample amount
- A few µg - 1,000 µg
- Sample vial volume
- 650 µl
- Vial closure
- PE cap, uncapped by ASPIROS mechanics
- Identification
- Bar code reader (optional)
- Configured to your application by our specialists
- Installed and commissioned on site
- Training and after-sales support across Jordan, the GCC and MENA
ASPIROS micro dosing unit
Request a quoteOverview
Product overview
ASPIROS is intended for very small quantities of dry, valuable or toxic substances. It mounts in place of the RODOS funnel and is used with HELOS, or as ASPIROS/L with QICPIC.
Sample is filled in a glove box or fume cabinet into a sealed 650 µl glass vial, which is inserted into the unit. The system uncaps the vial under software control and releases the sample into the RODOS injector, so the product never contacts the surroundings. An optional bar code reader identifies the sample and applies the matching dispersion settings, and the vials can be used as disposables.
Specifications
Technical specifications
5 parameters
Range
- Sample amount
- A few µg - 1,000 µg
Design
- Sample vial volume
- 650 µl
- Vial closure
- PE cap, uncapped by ASPIROS mechanics
Options
- Identification
- Bar code reader (optional)
Compatibility
- Use with
- HELOS; ASPIROS/L with QICPIC; RODOS
Features
Key features
- 01
Micro quantities
A few micrograms up to about 1,000 µg.
- 02
Closed system
No contact between product and environment.
- 03
Bar code option
Automatic sample identification.
- 04
Disposable vials
650 µl sealed glass vials.
From order to operation
We stay with the instrument after it arrives
Al-Shaker specifies the configuration, documents the system, and supports it across Jordan, the GCC, and MENA.
- 01
Consult
- 02
Plan
- 03
Supply
- 04
Install
- 05
Train
- 06
Support
